PSMB (Polysurlyn Moisture Barrier) aluminum coils are specially designed materials for roofing and insulation applications. PSMB Polysurlyn Moisture Barrier Aluminum Coils provide excellent moisture protection and enhance the durability of the building structure. The Polysurlyn layer acts as a moisture barrier, preventing water penetration and condensation, thereby preventing structural damage and mold growth.
Features of PSMB Polysurlyn Moisture Barrier Aluminum Coils
1. Moisture Resistance
The Polysurlyn coating effectively prevents moisture penetration, ensuring that the underlying materials remain dry and protected from water damage.
2. Durability
Aluminum has anti-rust and corrosion-resistant properties, making PSMB coils suitable for various environmental conditions. The combination of aluminum and Polysurlyn extends the overall lifespan of the product.
3. Lightweight
Aluminum coils are lightweight, making them easy to handle and install. This feature can reduce labor costs and installation time.
4. Thermal Performance
The moisture barrier helps maintain the thermal efficiency of the building system by minimizing heat loss or gain, resulting in energy savings.
5. Versatility
PSMB coils can be used for a variety of applications, including commercial and residential roofing, insulation systems, and HVAC duct systems.
6. Customizable
The coils can be manufactured in various thicknesses, widths, and lengths to meet specific project requirements. Custom printing and branding options are also available.
PSMB Polysurlyn Moisture Barrier Aluminum Coils规格
- Alloy: 1050, 1060, 3003 , 3105 etc
- Specification: 0.1-2.0mm/200-1200mm/ Coil or as per requirements
- Barrier: 76 microns blue barrier
- Protection: plastic film covered
- Standard width: 914mm 1000mm 1200mm 1219mm
- Surface:Plain, Flat, Mill finish, Smooth, Stucco embossed
- Coatings: PE/PVDF Coated, PolySurlyn Polykraft paper Laminated
- Kraft paper thickness: about 0.1mm
- Polysurlyn thickness: about 0.076mm (3mil)
- Inner diameter: 305mm, 405mm or 505mm with paper core or without core
- Out diameter: 125m, 150m, 250m , 300m, 500m, 1000m, 2540m or according to coil weight
- Quality standard: ASTM B209 EN573-1
PSMB Polysurlyn Moisture Barrier Aluminum Coils应用
Roofing Systems
In metal roofing applications, PSMB Polysurlyn moisture barrier aluminum coils are used as a moisture barrier. Their main functions include:
- 1. Waterproof Performance: These aluminum coils effectively prevent moisture penetration, protecting the roofing structure from water damage and extending the roof's lifespan.
- 2. Weather Resistance: Aluminum materials have excellent weather resistance, making them less susceptible to UV rays and extreme weather, ensuring the durability of the moisture barrier.
- 3. Easy Installation: The lightweight nature of PSMB Polysurlyn aluminum coils simplifies the installation process, saving construction time and costs.
Insulation
In insulation systems, the application of PSMB Polysurlyn aluminum coils is primarily reflected in the following aspects:
- 1. Humidity Control: This material effectively blocks moisture intrusion, preventing insulation materials from failing due to dampness and maintaining stable insulation performance.
- 2. Enhanced Thermal Performance: The reflective properties of the aluminum coil surface can reduce heat absorption, thereby improving the thermal performance of the building and lowering air conditioning and heating energy consumption.
- 3. Overall Efficiency: By combining PSMB Polysurlyn aluminum coils with other insulation materials, more efficient energy management can be achieved, enhancing the overall energy efficiency of the building.
HVAC (Heating, Ventilation, and Air Conditioning)
In HVAC systems, PSMB Polysurlyn moisture barrier aluminum coils primarily serve as a protective layer, with specific advantages including:
- 1. Reduced Condensation: Using PSMB Polysurlyn aluminum coils in duct systems can effectively reduce the formation of condensation, preventing water droplets from damaging the ducts and surrounding environment.
- 2. Improved Energy Efficiency: The reflective properties and moisture barrier performance of the aluminum coils help HVAC systems maintain optimal operating conditions, reducing energy consumption and enhancing overall energy efficiency.
- 3. Durability: PSMB Polysurlyn aluminum coils exhibit outstanding corrosion resistance and physical strength, ensuring stability and functionality over extended use.
PSMB Polysurlyn moisture barrier aluminum coils, with their excellent moisture resistance, weather resistance, and thermal reflective properties, have become indispensable materials in the construction industry. Through their applications in roofing, insulation, and HVAC systems, they not only extend the lifespan and energy efficiency of buildings but also provide better comfort and safety.
PSMB Polysurlyn Moisture Barrier Aluminum Coils Chemical Composition
| Alloy Grade | Aluminum (Al) | Copper (Cu) | Manganese (Mn) | Magnesium (Mg) | Silicon (Si) | Iron (Fe) | Zinc (Zn) | Other Elements |
| 1050 | 99.50% | ≤0.05% | ≤0.05% | - | ≤0.25% | ≤0.4% | - | - |
| 1060 | 99.60% | ≤0.05% | ≤0.05% | - | ≤0.25% | ≤0.4% | - | - |
| 3003 | 97.00% | 0.12-0.20% | 1.00-1.50% | - | ≤0.60% | ≤0.70% | - | - |
| 3105 | 95.00% | 0.05% | 0.50-1.00% | 0.20-0.60% | ≤0.50% | ≤0.70% | 0.10-0.50% | - |
